With the vast and diverse energy requirements of modern aviation, getting into the air is only the beginning.

AERO-SOCTESTER™ battery analyzers were developed as fast and accurate field test instruments with the capability of determining the ability of sealed lead-acid (calcium) batteries to perform for specific periods of time.  The measurement developed determines the “State-of-Charge” (SOC), by examining the battery’s internal profile characteristics.



AERO-SOCTESTER BATTERY ANALYZER SPECIFICATIONS

VOLTAGE RANGE

12V, 24V

BATTERY RATING

1 - 70 Ampere Hour @ 20 HOUR RATE

BATTERY TYPE

Sealed Lead-Acid

TEST CYCLE TIME

43 seconds

CABLE SET

6 FT replaceable

RESOLUTION

5%

SIZE

14.875" x 12.125" x 6.875"
(37.78cm x 30.79cm x 17.46cm)

WEIGHT

22 lbs

INTEGRATED
AUTO-PURGE SYSTEM

Available Completely watertight and airtight. With integrated Auto-Purge System. Our Pressure Release Purge Valve guarantees a perfect seal by incorporating its own O-Ring under one of the latches. You will never forget to set the valve since it automatically activates when closing the case. Pressure is released as you open the latch.

DURABILITY

CRUSH RESISTANCE manufactured to exceed crush resistance MIL STDs of 400 Lbs stacking

Specifications subject to change without notice.  Every SOCTESTER™ battery analyzer is delivered with factory calibration for sealed lead-acid (calcium) batteries with nominal resistance.  Recommended calibration every 2 years for optimal performance and accuracy All SOCTESTER™ battery analyzers come with 6ft. test cables, Internal battery, AC Wall plug power unit, Factory calibration and a full 90 day warranty Patented



AERO-SOCTESTER™ battery analyzers were developed to quickly and accurately determine the ability of vent regulated lead acid (VRLA) batteries to perform for specific periods of time, whether in inventory or in the field.  AERO-SOCTESTER™ battery analyzers scan the infrastructure of the battery and exercise it to measure its ampere hour capacity, its ability to supply relatively large currents, and whether it is fully charged.

The AERO-SOCTESTER then determines the battery’s energy profile, quickly computes the battery’s characteristics, and displays the battery’s SOC (State of Charge).  All in just 43 seconds.

Tests 12 Volt and 24 Volt
SLA, VRLA, GEL & AGM Batteries
1 Ahr to 70 Ahr
